Product Overview

Key Features

• Unit to be mounted on 50mm height adjustable feet in stainless steel.
• Deep drawn V-Shaped well.
• Two high efficiency 7 kW burners in stainless steel with flame failure device attached to the outside of the well.
• Thermostatic regulation of oil temperature up to a maximum of 185 °C.
• Flame failure device on each burner
• Overheat protection thermostat as standard on all units.
• Oil drains through a tap into a drainage container positioned under the well.
• All major compartments located in front of unit for ease of maintenance.
• Piezo spark ignition for added safety.
• Gas appliance supplied for use with natural or LPG gas, conversion jets supplied as standard.
• IPx4 water protection.
• Optional portable oil quality monitoring tool (code 9B8081) for efficient oil management.

Construction

• Interior of well with rounded corners for ease of cleaning.
• All exterior panels in Stainless Steel with Scotch Brite finishing.
• One piece pressed 1.5 mm work top in Stainless steel.
• Model has right-angled side edges to allow flush fitting joints between units, eliminating gaps and possible dirt traps.
• If appliance is set up or next to or against temperature sensitive furniture or similar, a safety gap of approximately 150 mm should be maintained or some form of heat insulation fitted.
• Certification group: N7FG
